Description
The Xs series of system scales may be used in stand-alone mode or linked together to form
departments networks; in addition, the different departments can be linked together and connected
to a back office computer, to form store-wide, centrally managed networks.
Dual currency pricing, PLU search, Audit Trail and transaction collection, 9 security levels, 99 departments, 99 sales messages, 10 tax rates, 39 tares, 20 discount rates, 15 payment keys, Vertical scrolling messages, Cash up
Specification
Processor & Memory User-programmable data is stored in 2 MB of reprogrammable ‘Flash’ memory. There is an additional 14 MB Flash memory which is used for the application software and factory default data Standard build includes 2.0 Megabyte static RAM (SRAM). An additional 2 MB card is available to extend the SRAM capacity to a total of 4MB. The number of PLU’s supported is dependent on the memory size available and the average text size. For a 2MB memory machine, an average text of 25 characters (receipt mode) will typically allow 7000 PLUs. Average text of 400 characters (label mode) will typically allow 3000 PLUs. Displays All Xs series customer and vendor displays are, LCD dot-matrix 320 x 128 dot resolution displays with white LED backlight. The layout of the display is designed to provide all relevant information according to its mode of operation, whilst providing an easy-to-use interface for the customer and vendor. Date and time are permanently displayed, along with a status area showing network status, printer status, label / receipt mode and activity indicator. The top left-hand corner of the display is reserved to allow a logo to be permanently displayed. Different character sets can be supported for the various countries, including Latin, Greek and Arabic. Printers The Xs series printer is a heavy duty label and receipt printer, with a single motor driving both the paper feed and paper rewind systems. Receipt tally roll, die cut labels or continuous sticky paper can be used. The paper roll is loaded onto the spindle and the paper passed through the large aperture at the rear of the open print mechanism. The single large aperture through which the paper is fed at the rear of the print mechanism means paper changes are quick and simple and makes it virtually impossible to feed the paper through the printer incorrectly. To ensure the print head can be cleaned easily, the print head is raised well clear of the lower body when in the open position ensuring good access; this easy maintenance feature encourages cleaning to be carried out and the life of the print head optimised. The printer also auto-rewinds before printing commences, ensuring a minimum of dead space on the label or receipt.
